CNC machined steering knuckles correctly drilled for the application.
Heavy 1/4" thick crossmembers.
No track width change.
Differential skid plate included.
Includes Nitro rear shocks.
Brand: Zone Offroad
Recommended Tire/Wheel:
37x12.50, 18x9, 5" backspacing
35x12.50, 18x9, 4.5"-5" backspacing
37x12.50, 20x9, 5"-5.5" backspacing
Vehicle Application:
2014 Ford F150 2WD
Notes:
Will not work with 17" wheels.
If using 18x9 wheels with 5.5" backspace, fit the wheels before mounting to check the proper tie rod clearance. Wheel manufacturing variances may affect this clearance.
Vehicles equipped with factory powersteps will require E-brake relocation bracket (sold separately).
Vehicles equipped with a 2-piece driveshaft and carrier bearing may require carrier bearing drop (sold separately).
