Rough Country
Electric Tilt Windshield Glass Honda Pioneer 1000/1000-5 98316222
Quantity:
Choose options
Quantity:
Rough Country Electric Tilt Windshield | Glass | Honda Pioneer 1000/1000-5
Description:
Maximum Durability and Visibility. Say hello to a whole new view with Rough Country's Auto-Tilt Glass Windshield for the Honda Pioneer 1000/1000-5. With its DOT-approved glass and sturdy construction, this windshield is less likely to crack or break, even when driving through rough terrain. The Auto-Tilt Glass Windshield for Honda Pioneer is the perfect accessory for your off-road vehicle, giving you unobstructed visibility. Our windshield is built to make your ride safer, so you can focus on the trail ahead.
Heavy-Duty Reliability. The Auto-Tilt Windshield is installed in a heavy-duty metal frame with UV and scratch-resistant powder coating that can withstand all weather conditions. And with weather seal protection, the glass will stay in excellent condition for years to come. It features an easy-to-use rocker switch, so you can open the windshield slightly for minimum airflow or fully open it for maximum airflow. The push-button control with dual linear actuators is so easy to use that you can even adjust mid-ride. The glass is built for long-lasting reliability because the rugged design of your Pioneer deserves a windshield that is just as tough.
Installation. Our new Auto-Tilt Glass Windshield can be installed on Honda Pioneer models for a clear view and added protection. The windshield comes with the hardware needed for an easy install that includes some minor drilling.
Warranty. Rough Country's Auto-tilt Glass Windshield is backed with a limited lifetime replacement warranty towards manufacturer defects. As such, the product is protected from structural and workmanship damage after the date of purchase. With our industry-leading warranty, give yourself peace of mind when using Rough Country's products!
Features:
Frame Dimensions Width: 50.75" Height: 29.5"
Glass Dimensions Width: 44.66" Height: 21.75"
Metal Frame with UV and Scratch Resistant Powder Coating.
DOT Approved Glass - Scratch & Impact Resistant Electrically actuated with position control - Open slightly for airflow or fully open for max airflow.
Open and close with the push of a button.
Edge seal creates a seal against the face of the vehicle blocking out most dust and water.
Easy installation.
Cylinder Specifications: Input Voltage: 12V
Stroke: from 382+-3mm to 586+-3mm
Force: 410N.
Max support 45KGs Speed(no load): 10mm/s
IP Rating: IP65 Working Temp: -5-50C
Current(full load): 5A
Notes:
Fits with most factory roofs but in some cases requires the roof to be trimmed 1/4" to 3/8"
along the front edge to clear windshield movement.
Install Time:
1-2 hours
Fitment:
2017-2019 4WD Honda SXS1000M3 Pioneer 1000 Limited Edition
2017-2021 4WD Honda SXS1000M5 Pioneer 1000-5 Limited Edition
2016-2023 4WD Honda SXS1000M5 Pioneer 1000-5
2020-2023 4WD Honda SXS1000M3 Pioneer 1000 Deluxe
2016-2023 4WD Honda SXS1000M3 Pioneer 1000
2016-2023 4WD Honda SXS1000M5 Pioneer 1000-5 Deluxe
